1010music Synthbox Module With Touchscreen

Description

Use the touchscreen to choose and shape the waveforms and to apply the built in sound effects. Modulate the waves and the effects using a combination of on screen controls of envelopes, low frequency oscillators, and sequencers together with hard wired CV inputs to tweak the sound to meet your creative vision.FeaturesMIDI controllable with support for velocity, pitch bend, and modulation wheel CV controllable with pitch, gate, and 3 assignable modulators per voice 24 bit DACs and internal processing 8 wavetable oscillators 4 waveform oscillators 2 filters, 2 envelopes, 2 LFOS, and a step sequencer per voice Global flanger, distortion, and stereo delay effects Semi-modular control Stereo or individual voice outputs Comes with 50 presets and 100 wavetables Supports user wavetables from WAV file Specifications26 HP +12V: 350mA -12V: 0mA 5V: 0mA Weight: 0.78 lbs Dimension: 6.75 × 6.25 × 2.125 inWhat is includeda Series 1 eurorack module with a synthbox faceplate a microSD card with synthbox firmware loaded on it a eurorack power cable a synthbox Quick Start guide a MIDI Adapter Watch: Synthbox 1.0 Demo
