Botex NETcon 8-3

Description

Bidirectional Art-net Node

• Configure via integrated display directly on the device
• RDM capable
• Adjustable DMX repetition rate (10-40 Hz)
• 4096 Channels / eight DMX universes
• Convert either Art-Net to DMX or DMX to Art-Net
• LEDs for visualising the transmission status of network and DMX signal
• Supported protocols: DMX, RDM, Art-Net
• 2 Ethernet RJ45 connections, lockable
• 8 XLR 3-pin female DMX inputs and outputs
• Power Twist for current input and output
• Power supply: AC 90 – 250 V at 50/60 Hz
• Power consumption: 7.5 W
• Protection: IP20
• Black metal case
• Dimensions: 483 x 169 x 49 mm
• Weight: 2 kg
• Build: 19″ / 1 U

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since September 2019

• Item number 464561

• Sales Unit 1 piece(s)

• Type Ethernet-Interface

• Type of construction 19″-housing

• Connection for PC/Ethernet RJ45

• Universes (Outputs) 8

• DMX-Output 3-pole XLR female

• DMX-Input 3-pole XLR female

• RDM-capable Yes

• Internal memory No
