Description
Eurorack Module
- Flexible function generator with VCA
- Possible applications: AD or ASR envelope, LFO, oscillator, frequency divider, wave shaper, envelope follower, ring modulator, VCA and more
- Attack and decay time (rise / fall) separately adjustable and each controllable via CV input
- Adjustable characteristic curve for rise and fall segment
- Switchable cycle mode
- VCA / four-quadrant multiplier with adjustable bias and CV input with attenuator
- Rectify input (rectifier)
- Bound input for generating “bouncing ball” envelopes
- Inputs for trigger, slew, rise CV and fall CV
- EOR and signal output for function generator
- Signal input/output and 2 CV inputs for VCA section
- Current consumption: 112 mA (+12 V) / 59 mA (-12 V)
- Width: 12 TE
- Depth: 25 mm
30 30-Day Money-Back Guarantee
3 3-Year Thomann Warranty
-
Available since January 2022
-
Item number 535295
-
Sales Unit 1 piece(s)
-
Width 12 TE / HP
-
linear Yes
